ASUS Pro B660M-C D4-CSM mATX Motherboard
16,800.00৳
| Key Feature | Quick Insight |
|---|---|
| CPU Compatibility | Intel 14th, 13th, 12th Gen (LGA1700) |
| Memory Support | DDR4, up to 128GB, 4 DIMMs, 5000MHz (OC) |
| Storage Interface | 2 x M.2 PCIe 4.0 x4, 4 x SATA with RAID |
| Expansion Ready | PCIe 4.0 x16 + 2 x PCIe 3.0 x1 |
| Display Outputs | Dual DisplayPort, HDMI, D-Sub |
| Connectivity | USB 3.2 Gen 1, USB Type-C, Intel LAN |
| Audio Quality | Realtek 7.1 HD Audio, Premium Codec |
| Enterprise Features | ASUS CSM program, ACCE Software, TPM, Debug tools |
| Durability & Protection | Anti-moisture, Overcurrent Protection, 24/7 Reliability |
| Best For | Business Builds, IT Deployments, Commercial Use |
Description
| Feature Category | Description |
|---|---|
| Model | ASUS Pro B660M-C D4-CSM |
| Socket | Intel LGA1700 |
| Supported CPU | 14th/13th/12th Gen Intel Core, Pentium Gold, Celeron |
| Chipset | Intel B660 |
| Form Factor | microATX (24.4 cm x 24.4 cm) |
| BIOS | 128Mb Flash ROM |
| Memory Support | 4 x DDR4 DIMM, up to 128GB, Dual ChannelUp to 5000 MHz (OC), Intel XMP support |
| Expansion Slots | 1 x PCIe 4.0/3.0 x16 (CPU)2 x PCIe 3.0 x1 (Chipset) |
| Storage Interface | 2 x M.2 PCIe 4.0 x4 (2242/2260/2280)4 x SATA 6Gb/s, Intel RST RAID 0/1/5/10 |
| Graphics Output | 2 x DisplayPort (4K@60Hz)1 x HDMI (4K@60Hz)1 x D-Sub |
| Audio | Realtek 7.1 HD Audio CODECSupports 24-bit/192kHz playback |
| USB Ports (Rear) | 2 x USB 3.2 Gen 1 (Type-A)2 x USB 2.0 (Type-A) |
| USB Ports (Front) | 1 x USB 3.2 Gen 1 (Type-C)1 x USB 3.2 Gen 1 header (2 ports)2 x USB 2.0 headers (4 ports) |
| LAN | 1 x Intel 1Gb Ethernet (with ASUS LANGuard) |
| Wireless Support | 1 x M.2 Key E slot for Wi-Fi module (sold separately) |
| Internal Headers | 1 x 24-pin ATX Power1 x 8-pin CPU Power2 x M.2 (Key M)2 x Chassis Fan, 1 x CPU Fan1 x TPM header, 2 x COM headers, 1 x Debug header1 x Front Audio, 1 x LPT, 1 x Mono-out, 1 x Speaker |
| Back Panel I/O | 2 x USB 3.2 Gen 1, 2 x USB 2.01 x HDMI, 2 x DisplayPort, 1 x D-Sub1 x LAN, 3 x Audio jacks |
| Special Features | ASUS Control Center Express (ACCE)ASUS Corporate Stable Model (CSM)TPM IC onboardSelf Recovering BIOS, Event Log, Anti-Moisture Design24/7 Reliability, Overcurrent Protection |
| Software Bundle | ASUS ACCE, IT Management SoftwareEZ DIY Tools (Q-LED, Debug Card Support) |
| Cooling Support | 2 x Chassis Fans, 1 x CPU Fan Header |
| Warranty | 2 Year Official Warranty (1 year parts/labor, no on-site) + 1 Additional Year from Takeplus Computer |
| Price in Bangladesh | ৳16,300 Takeplus Computer |
