Dahua DH-XVR1B04-I-SSD-1TB 04 Channel 1080N/720P XVR
7,500.00৳
| Key Feature | Details | ||
|---|---|---|---|
| Channels | 4 Analog + Up to 5 IP (Hybrid Mode) | ||
| Built-in Storage | 1TB SSD (default); replaceable with 256GB or 512GB | ||
| AI Smart Detection | 4-Channel SMD Plus (Human/Vehicle Filtering) | ||
| Video Compression | AI Coding, H.265+, H.265, H.264+, H.264 | ||
| Maximum Resolution | 1080p | ||
| Dual Stream Support | Yes | ||
| Two-way Audio | Yes (via RCA input, shared with 1st channel) | ||
| Mobile Access | Android & iOS | ||
| Third-party Support | ONVIF, Sony, Axis, Panasonic, Arecont, Samsung | ||
| Backup Methods | USB Device, Network | ||
| Browser Access | Chrome, Firefox, Internet Explorer 9+ | ||
| Display Layout | 1/4 (Normal), 1/4/6 (with IP extension) | ||
| Low Power Design | Only <7W with SSD, compact & energy efficient | ||
| Warranty |
|
Description
| Feature | Description | |
|---|---|---|
| Brand | Dahua | |
| Model | DH-XVR1B04-I-SSD-1TB | |
| Type | 1080N/720P Penta-brid XVR | |
| Operating System | Embedded Linux | |
| Processor | Industrial-grade processor | |
| Operating Interface | Web, Local GUI | |
| Analog Camera Input | 4 BNC ports (HDCVI/AHD/TVI/CVBS auto-detect) | |
| IP Camera Input | Up to 5 channels (Max 2MP each) | |
| CVI Input | 1080p @25/30fps, 720p @25/30/50/60fps | |
| TVI Input | 1080p @25/30fps, 720p @25/30fps | |
| AHD Input | 1080p @25/30fps, 720p @25/30fps | |
| Maximum Recording Resolution | 1920 × 1080 | |
| Video Compression | AI Coding, H.265+, H.265, H.264+, H.264 | |
| Video Bit Rate | 32 kbps – 4096 kbps per channel | |
| Audio Input | 1-channel RCA + 4-channel BNC (coaxial audio) | |
| Audio Output | 1-channel RCA | |
| Audio Compression | G.711a, G.711u, PCM | |
| Audio Bit Rate | 64 kbps | |
| Audio Sampling Rate | 8 kHz, 16-bit | |
| Two-way Audio | Yes (shares input with 1st channel) | |
| Dual Stream Support | Yes | |
| Frame Rate | PAL: 1–25 fps, NTSC: 1–30 fps | |
| Recording Modes | General, Motion Detection, Intelligent, Alarm | |
| Recording Playback | 1/4 channels | |
| Playback Modes | Instant, General, Event, Tag, Smart Playback (MD) | |
| Backup | USB Device, Network | |
| Smart Features (AI) | 4-Channel SMD Plus (Human/Vehicle filtering) | |
| Alarm Functions | Motion Detection, Intelligent, Video Loss, Alarm | |
| Alarm Linkage | Record, Snapshot, Email, Log, Buzzer, Voice Prompt | |
| Video Output | 1 HDMI, 1 VGA (1920×1080, 1280×1024, 1280×720) | |
| Display Layout | Normal: 1/4 | |
| Third-Party Camera Support | ONVIF, Axis, Panasonic, Sony, Arecont, Samsung | |
| Network Interface | 1× RJ45 (10/100 Mbps) | |
| Network Protocols | HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, P2P | |
| Browser Compatibility | Chrome, Firefox, Internet Explorer 9+ | |
| Mobile Access | Android, iOS | |
| HDD Storage | 1× SSD 1TB pre-installed (Replaceable with 256GB or 512GB) | |
| Storage Duration | Up to 44 Days (Default setting) | |
| USB Ports | 2× USB 2.0 (rear) | |
| Power Supply | 12V DC, 1.5A | |
| Power Consumption | < 7W (with SSD) | |
| Dimensions (W × D × H) | 198.3 × 202.9 × 41.5 mm | |
| Net Weight | 0.57 kg | |
| Color | Black | |
| Warranty |
(No warranty for physical/burn damage) |
|
| Country of Origin | China |
