Gigabyte A520M K V2 DDR4 AM4 Socket AMD Motherboard
Original price was: 8,900.00৳ .8,200.00৳ Current price is: 8,200.00৳ .
| Quick Overview | Details |
|---|---|
| Chipset | AMD A520 |
| Sockets Supported | AM4 |
| Supported CPU | AMD Ryzen 5000 G-Series / 5000 Series / 4000 G-Series / 3000 Series |
| Generation | Not Applicable |
| Memory Slot | 2 |
| Maximum Memory Support | 64GB |
| Back-Connect Design | No |
Description
| Specification Category | Details |
|---|---|
| Brand | Gigabyte |
| Model | A520M K V2 |
| Chipset | AMD A520 |
| CPU Socket | AM4 |
| Supported CPUs | AMD Ryzen 5000 G-Series / 5000 Series / 4000 G-Series / 3000 Series |
| Built-in Processor | No |
| Memory Type | DDR4 (Dual Channel, Non-ECC/ECC Unbuffered) |
| Memory Slots | 2 x DIMM |
| Max Memory | 64GB |
| Supported Memory Speeds | 2133 / 2400 / 2667 / 2933 / 3200 / 3400(O.C.) / 3466(O.C.) / 3600(O.C.) / 3733(O.C.) / 3866(O.C.) / 4000(O.C.) / 4133(O.C.) / 4266(O.C.) / 4400(O.C.) and above |
| Integrated Graphics | Yes (depends on processor) |
| Expansion Slots | 1 x PCIe 3.0 x16, 1 x PCIe 3.0 x1 |
| M.2 Slot | 1 x M.2 (Type 2280, PCIe 3.0 x4/x2 & SATA support) |
| SATA Ports | 4 x SATA 6Gb/s |
| Audio | Realtek High Definition Audio, 2/4/5.1/7.1 channel support |
| LAN | Realtek GbE LAN, 10/100/1000 Mbps |
| USB Ports | 4 x USB 3.2 Gen 1 Type-A, 2 x USB 2.0 Type-A |
| Video Outputs | 1 x HDMI, 1 x VGA (D-sub) |
| RAID Support | 0, 1, 10 |
| Form Factor | Micro-ATX |
| OS Compatibility | Windows 10 / 11 |
| BIOS | AMI UEFI BIOS (128Mbit flash), PnP 1.0a, DMI 2.7, WfM 2.0, SMBIOS 2.7, ACPI 5.0 |
| Special Features | PCIe Gen3 x4 M.2 with NVMe & SATA, Smart Fan 5, Hybrid Fan Headers with Fan Stop, GIGABYTE APP Center, HDMI + VGA multi-display |
| Internal I/O | 1 x 24-pin ATX, 1 x 8-pin 12V, CPU/System fan headers, Clear CMOS, chassis intrusion, speaker, M.2, SATA, audio & front panel headers |
| Power Consumption | Approx. 60W |
| Color | Black |
| Warranty | No warranty |
| Country of Origin | Taiwan |
| Assembled in | China |
| Price in Bangladesh | Starting from ৳8,200 (subject to availability and configuration) |
