-4%
GIGABYTE INTEL B860M D3HP LGA1851 Motherboard
Original price was: 25,000.00৳ .23,999.00৳ Current price is: 23,999.00৳ .
GIGABYTE INTEL B860M A ELITE WIFI6E LGA1851 Motherboard
Original price was: 34,000.00৳ .32,999.00৳ Current price is: 32,999.00৳ .
GIGABYTE INTEL B860M GAMING WIFI6 LGA1851 Motherboard
Original price was: 26,000.00৳ .24,999.00৳ Current price is: 24,999.00৳ .
| Feature | Why It Matters |
|---|---|
| Next-Gen Ready | Supports Intel® Core™ Ultra CPUs on the new LGA1851 socket |
| DDR5 Memory Power | Up to 128GB, speeds reaching DDR5-9066 MT/s with XMP support |
| Graphics Output Options | HDMI 2.1 and DisplayPort 2.1 for ultra-clear 4K & 144Hz visuals |
| Dual Expansion Power | PCIe 5.0 x16 for GPU/SSD + PCIe 4.0 x16 for additional devices |
| High-Speed Storage | Dual M.2 slots (PCIe 5.0 + PCIe 4.0) plus 4 × SATA with RAID |
| Enhanced Connectivity | USB 3.2 Gen1, USB Type-C, plus multiple legacy ports |
| Wi-Fi 6 & Bluetooth 5.3 | Reliable wireless networking with next-gen standards |
| Advanced Cooling Support | Multiple fan/pump headers and ARGB Gen2 headers |
| Robust System Tools | Q-Flash Plus BIOS updates, Smart Backup, GCC monitoring |
| Warranty | Total 3 Years Warranty by Takeplus Computer |
Description
| Category | Details |
|---|---|
| CPU Support | Intel® Core™ Ultra Processors (LGA1851 socket) (Refer to GIGABYTE website for complete CPU list) |
| Chipset | Intel® B860 Express |
| Cache | L3 cache varies with CPU |
| Memory Support | DDR5 5600 – 9066 MT/s (OC) 2 × DDR5 DIMM sockets, up to 128GB (64GB per DIMM) Dual channel architecture Supports ECC Un-buffered DIMM (non-ECC mode) Supports Non-ECC DIMM 1Rx8/2Rx8/1Rx16 Extreme Memory Profile (XMP) support |
| Graphics (Integrated) | Intel® HD Graphics (depends on CPU) |
| Video Outputs | 1 × HDMI 2.1 (4096×2160 @ 60Hz, HDCP 2.3) 1 × DisplayPort 2.1 (3840×2160 @ 144Hz) |
| Audio | Realtek® HD Audio CODEC 2/4/5.1/7.1-channel S/PDIF Out supported |
| Networking | Realtek® 2.5GbE LAN (2.5G/1G/100M) |
| Wireless | Realtek® Wi-Fi 6 RTL8851BE Supports 2.4GHz & 5GHz bands Bluetooth 5.3 802.11ax 80MHz wireless standard |
| Expansion Slots | CPU: 1 × PCIe 5.0 x16 (GPU or NVMe SSD only) Chipset: 1 × PCIe 4.0 x16 (runs at x4) |
| Storage Interfaces | CPU: 1 × M.2 PCIe 5.0 x4/x2 (M2A_CPU) Chipset: 1 × M.2 PCIe 4.0 x4/x2 (M2P_SB) 4 × SATA 6Gb/s connectors RAID 0, 1, 5, 10 |
| USB Ports | Rear I/O: 3 × USB 3.2 Gen1, 3 × USB 2.0/1.1, 1 × PS/2, 2 × antenna connectors Internal: 1 × USB Type-C (3.2 Gen1), 1 × USB 3.2 Gen1 header, 4 × USB 2.0 headers |
| Internal I/O Connectors | 24-pin ATX, 8-pin ATX 12V CPU/system/pump fan headers 3 × ARGB Gen2 headers 2 × M.2 sockets 4 × SATA connectors Front panel header, front audio header S/PDIF Out header USB Type-C header (3.2 Gen1) USB 3.2 Gen1 header 2 × USB 2.0 headers TPM header Serial port header Q-Flash Plus button Reset jumper Clear CMOS jumper |
| Back Panel Connectors | 1 × PS/2 1 × HDMI 1 × DisplayPort 3 × USB 3.2 Gen1 3 × USB 2.0/1.1 2 × Wi-Fi antenna connectors 1 × RJ-45 LAN port 3 × audio jacks |
| I/O Controller | iTE® Controller Chip |
| H/W Monitoring | Voltage, temperature, fan speed & water flow detection Fan fail warning Fan/pump speed control (depends on installed device) |
| BIOS | 256 Mbit flash AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features | GIGABYTE Control Center (GCC) Q-Flash & Q-Flash Plus Smart Backup |
| Bundled Software | Norton® Internet Security (OEM) LAN bandwidth management software |
| OS Support | Windows 11 64-bit (Intel® NPU driver required) Windows 10 64-bit |
| Form Factor | Micro ATX, 24.4 × 22.5 cm |
| Warranty | 2 Years officially Warranty + 1 Additional Year Warranty from Takeplus Computer (No Warranty for External Damages) |
