GIGABYTE B550M H AM4 Mico-ATX Motherboard
Original price was: 17,000.00৳ .13,000.00৳ Current price is: 13,000.00৳ .
| Key Features | Description |
|---|---|
| Model | GIGABYTE B550M H |
| Processor Compatibility | AMD Ryzen 5000 Series / 3rd Gen Ryzen / 3rd Gen Ryzen with Radeon Graphics Processors |
| Networking | GIGABYTE Exclusive Realtek 8118 Gaming LAN with bandwidth management |
| Audio | High Quality Audio Capacitors delivering high-resolution sound |
| Power Design | 4+3 Phases Pure Digital VRM for stable and efficient power delivery |
Description
| Specification Category | Details |
|---|---|
| Brand | GIGABYTE |
| Model | B550M H |
| CPU Socket | AMD Socket AM4 |
| Supported CPU | AMD Ryzen 5000 Series / 3rd Gen Ryzen / 3rd Gen Ryzen with Radeon Graphics |
| Chipset | AMD B550 |
| Form Factor | Micro ATX (24.4cm x 20.5cm) |
| BIOS | AMI UEFI BIOS, 256Mbit Flash, PnP 1.0a, DMI 2.7, WfM 2.0, SMBIOS 2.7, ACPI 5.0 |
| Memory Type | DDR4 (Dual Channel) |
| Memory Slots | 2 x DIMM |
| Max Memory Support | Up to 64GB (32GB per DIMM) |
| Supported Memory Speeds | Up to 5100 MHz (OC), varies by CPU generation |
| ECC Support | ECC/Non-ECC Unbuffered DIMMs Supported |
| XMP Support | Yes |
| Expansion Slots | 1 x PCIe x16 (supports PCIe 4.0/3.0 depending on CPU), 2 x PCIe x1 (PCIe 3.0) |
| Graphics Output | 1 x HDMI (4096×2160@60Hz), 1 x D-Sub (1920×1200@60Hz) |
| Integrated Graphics | Yes (requires AMD Ryzen with Radeon Graphics) |
| Max Shared Graphics Memory | 16GB |
| Storage Interface | 1 x M.2 (SATA & PCIe 4.0/3.0 x4/x2), 4 x SATA 6Gb/s (RAID 0, 1, 10) |
| Audio | Realtek ALC887 Codec, 2/4/5.1/7.1-Channel HD Audio |
| LAN | Realtek GbE LAN (1000/100 Mbps), Realtek 8118 Gaming LAN |
| USB Ports | 4 x USB 3.2 Gen 1 (rear), 2 x USB 3.2 Gen 1 (internal header), 6 x USB 2.0 (2 rear, 4 internal header) |
| Internal I/O Connectors | 24-pin ATX, 8-pin 12V, CPU fan, 2 x system fan, M.2, 4 x SATA, TPM, serial, RGB/ARGB, audio, USB 3.2 Gen 1, USB 2.0, front panel, speaker, Clear CMOS, chassis intrusion |
| Audio Features | High-End Audio Capacitors, Audio Noise Guard |
| Display Support | HDMI 2.1 (4K/60Hz, HDR, HDCP 2.3), D-Sub |
| Special Features | PCIe 4.0 Hardware, NVMe SSD Support, Q-Flash Plus, RGB Fusion 2.0, Smart Fan, EasyTune, Game Boost, APP Center, Anti-Surge & ESD Protection |
| Power Phase Design | 4+3 Phases Pure Digital PWM with Low RDS(on) MOSFETs |
| Warranty | 2-Year Manufacturer Warranty + 1-Year Additional from Takeplus Computer (No warranty for fan or cooler) |
| Country of Origin | Taiwan |
| Assembled in | China |
| Price in Bangladesh | 13000 taka only |
