-4%
GIGABYTE INTEL B860M D3HP LGA1851 Motherboard
Original price was: 22,000.00৳ .20,999.00৳ Current price is: 20,999.00৳ .
GIGABYTE INTEL B860M GAMING WIFI6 LGA1851 Motherboard
Original price was: 26,000.00৳ .24,999.00৳ Current price is: 24,999.00৳ .
GIGABYTE INTEL B860M D3HP LGA1851 Motherboard
Original price was: 25,000.00৳ .23,999.00৳ Current price is: 23,999.00৳ .
| Feature | Why It Stands Out |
|---|---|
| Next-Gen CPU Support | Built for Intel® Core™ Ultra processors on LGA1851 socket |
| Extreme Memory Performance | Supports DDR5 speeds up to 9066 MT/s, dual-channel with ECC/non-ECC DIMMs |
| Graphics Output | HDMI 2.1 and DisplayPort 2.1 for 4K 60Hz and 144Hz visuals |
| Future-Proof Expansion | PCIe 5.0 x16 for cutting-edge GPUs or ultra-fast NVMe SSDs |
| Flexible Storage | Dual M.2 PCIe 4.0 slots plus 4 × SATA 6Gb/s with RAID options |
| Premium Audio | Realtek® HD Audio with up to 7.1-channel surround sound |
| Reliable Networking | Realtek Gigabit LAN for stable high-speed connectivity |
| System Management | GCC software, Smart Backup, Q-Flash BIOS update |
| Durable Build | Compact Micro ATX with strong power delivery and cooling support |
| Warranty | Total 3 Years Warranty by Takeplus Computer |
Description
| Category | Details |
|---|---|
| CPU Support | Intel® Core™ Ultra Processors (LGA1851 socket) (Refer to GIGABYTE website for full CPU support list) |
| Chipset | Intel® B860 Express |
| Cache | L3 cache depends on CPU |
| Memory Support | DDR5 5600 – 9066 MT/s (OC) 4 × DDR5 DIMM sockets, up to 256GB (64GB per DIMM) Dual channel memory architecture Supports ECC Un-buffered DIMM (operates in non-ECC mode) Supports Non-ECC DIMM 1Rx8/2Rx8/1Rx16 XMP memory profile support |
| Graphics (Integrated) | Intel® HD Graphics (CPU dependent) |
| Video Outputs | 1 × HDMI 2.1 (4096×2160 @ 60Hz, HDCP 2.3) 1 × DisplayPort 2.1 (3840×2160 @ 144Hz) |
| Expansion Slots | CPU: 1 × PCIe 5.0 x16 (GPU / NVMe SSD) Chipset: 2 × PCIe 3.0 x1 |
| Storage Interfaces | CPU: 1 × M.2 PCIe 4.0 x4/x2 (M2A_CPU) Chipset: 1 × M.2 PCIe 4.0 x4/x2 (M2Q_SB) 4 × SATA 6Gb/s |
| RAID Support | RAID 0, 1, 5, 10 (for SATA devices) |
| Audio | Realtek® HD Audio CODEC 2/4/5.1/7.1-channel configuration 3 × audio jacks |
| Networking | Realtek® Gigabit LAN (10/100/1000 Mbps) |
| USB Ports | Rear I/O: 3 × USB 3.2 Gen1, 3 × USB 2.0/1.1, 1 × PS/2 Internal: 1 × USB Type-C (3.2 Gen1), 1 × USB 3.2 Gen1 header, 4 × USB 2.0 headers |
| Internal I/O Connectors | 24-pin ATX main power, 8-pin ATX 12V CPU/system/pump fan headers 2 × ARGB Gen2 headers, 1 × RGB header 2 × M.2 sockets, 4 × SATA connectors Front panel header, front audio header USB Type-C header, USB 3.2 Gen1 header, 2 × USB 2.0 headers Trusted Platform Module header Serial port header Clear CMOS jumper |
| Back Panel Connectors | 3 × USB 2.0 1 × PS/2 port 1 × DisplayPort 1 × HDMI 3 × USB 3.2 Gen1 1 × RJ-45 LAN port 3 × audio jacks |
| I/O Controller | iTE® Controller Chip |
| H/W Monitoring | Voltage detection Temperature detection Fan speed & water flow monitoring Fan fail warning Fan/pump speed control (depends on installed device) |
| BIOS | 256 Mbit flash AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features | GIGABYTE Control Center (GCC) Q-Flash Smart Backup |
| Bundled Software | Norton Internet Security (OEM) LAN bandwidth management software |
| Operating System Support | Windows 11 64-bit (NPU driver required) Windows 10 64-bit |
| Form Factor | Micro ATX, 24.4 × 24.4 cm |
| Warranty | 2 Years officially Warranty + 1 Additional Year Warranty from Takeplus Computer (No Warranty for External Damages) |
